Ethernet Interface
| 10/100/1000BaseT(X) Ports (RJ45 Connector) | 16-port, full/half-duplex mode; auto MDI/MDI-X; auto negotiation speed |
| 1000BaseFX Port | 4-port, SFP Interface |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x |
Optical Fiber
| Mode | Multi-mode | Single-mode |
| Transmission Distance | 2km | 20km |
| Center Wavelength | 1310nm | 1310nm |
| TX Power | -6 ~ -1 dBm | -9 ~ -3 dBm |
| RX Power | ≤-21 dBm |
≤-23 dBm |
| Transmission Rate | 1000Mbps | 1000Mbps |
| Fiber Core/Cladding Diameter |
50/125 μm, 62.5/125 μm |
8.3/125 μm, 9/125 μm, 10/125 μm |
Switching Performance
| Packet Forwarding Rate |
1,488,095 pps |
| Transmission Mode | Store-and-forward |
| MAC Address Table | 8 k |
| Packet Buffer Size |
4.1 Mb |
| Backplane Bandwidth | 40 Gbps |
| Maximum Jumbo Frame Size |
10 kB |
Power Parameters
| Input Voltage | 12/24/48 VDC (10.8 to 52.8 VDC) with dual redundant power inputs |
| Power Consumption | 600 mA @ 24 V Max |
| Overload Protection | Supported |
| Reverse Polarity Protection | Supported |
Physical Characteristics
| Housing | IP40-rated metal housing |
| Installation | DIN-rail mounting |
| Dimensions (W × H × D) | 5.91" × 4.72" × 2.48" (150 mm × 120 mm × 63 mm) |
| Weight | 1600g |
Environmental Limits
| Operating Temperature | -10℃ to 60℃ |
| Storage Temperature | -40℃ to 85℃ |
| Relative Humidity | 5% to 95% (Non-condensing) |
Standards and Certifications
| EMI | FCC Part15, CISPR (EN55022) Class A |
| EMS | IEC61000-4-2 (ESD) Level 3,
IEC61000-4-3 (RS) Level 3,
IEC61000-4-4 (EFT)Level 3,
IEC61000-4-5 (Surge) Level 3,
IEC61000-4-6 (CS) Level 3,
IEC61000-4-8 Level 3 |
| Shock | IEC 60068-2-27 |
| Freefall |
IEC 60068-2-32 |
| Vibration |
IEC 60068-2-6 |
Warranty
| Warranty | 5 Years |
